• Oil Seal : Nitrile butyl rubber
• Motor Shaft : SS - 420
• Motor Body Pipe : J4
• Motor Bush : LTB-4 / Teflon
• Thrust bearing assembly : SS - 420 & Carbon
• Diaphragm : High Nitrile Butyl Rubber
• Motor Base : Cast Iron / SS - 304
• Housing Set : Cast Iron / SS - 304
• Check Valve Housing : Cast iron / SS - 304
• Check Valve : SS-410
• Outer Shell : J4
• Impeller : Noryl / Nylon
• Bowl : Noryl / Cast Iron / SS
• Counter Bush : LTB-4 / SS - 304
• Pump Bush : NBR / LTB 4
• Pump Sleeve : SS-410
• Suction : Cast iron / SS - 304
• Pump Shaft : SS-410
• Coupling / Pump Couple : SS-410
• Motor portion covered with corrosive resistance Stainless steel J4 shell
• More durability and hygiene
• High operating efficiency
• Specially designed thrust bearing to withstand high axial thrust load
• Extremely hardwearing water lubricated bearing
• Thread type motor construction ensures service feasibility
• Specially designed Deep Drawn type pump ensures perfect alignment and Thereby increases the life of the pump set
• Designed for wide voltage operation
• Best alternative for JET & Compressor pump set
• Additional intermediate bearing in higher stage pumps.
