• High operating efficiency resulting in lower power consumption
• Good suction lift characteristics
• Specially designed for wide voltage operation
• Dynamically balanced rotating parts including rotor and impeller ensures minimum vibration and longer life
• Back pull-out design for easy servicing and repair
• Double shielded ball bearings, so no need of external lubrication
• Mechanical seal or stuffing box is provided as per customers requirement.

• Power Range : 2.2 Kw - 11.2 Kw (3.0 HP - 15.0 HP)
• Version : Three Phase, 380-415V, 50Hz AC Supply
• Speed : 2880 RPM
• Maximum Total Head : 70 Mtr.
• Maximum Flow Rate : 2200 LPM
• Maximum Suction Lift : 7 Mtr.
• Degree of Protection : IP 44
• Class of Insulation : B
• Maximum Ambient Tem. : 40 C
• Sealing : Stuffing Box
• Type of Duty : S1 (Continuous)
• Direction of Rotation : Three Phase, Electrically Reversible
• Nominal Pumpset Size (Suction X Delivery) : 50 X 40, 50 X 50, 65 X 50, 80 X 65, 80 X 80,100 X 80 and 100 X 100 (All size in mm)

• High operating efficiency resulting in lower power consumption
• Good suction lift characteristics
• Specially designed for wide voltage operation
• Dynamically balanced rotating parts including rotor and impeller ensures minimum vibration and longer life
• Back pull-out design for easy servicing and repair
• Double shielded ball bearings, so no need of external lubrication
• Mechanical seal or stuffing box is provided as per customers requirement.
