• High operating efficiency resulting in lower power consumption
• Good suction lift characteristics
• Inbuilt thermal overload protector in al single phase pumpsets
• Specially designed for wide voltage operation
• Dynamically balanced rotating parts including rotor and impeller ensures minimum vibration and longer life
• Back pull-out design for easy servicing and repair
• Double shielded ball bearings, so no need of external lubrication
• Mechanical seal is provided as per customers requirement.

• Power Range : 0.37Kw (0.5 HP)
• Version : Single Phase, 200-240V, 50Hz AC Supply
• Speed : 2880 RPM
• Maximum Total Head : 25 Mtr.
• Maximum Flow Rate : 2160 LPH
• Maximum Suction Lift : 5 Mtr.
• Degree of Protection : IP 44
• Class of Insulation : B
• Maximum Ambient Tem. : 40 C
• Sealing : Mechanical Seal
• Type of Duty : S1 (Continuous)
• Direction of Rotation : Single Phase, Clockwise from driving end
• Nominal Pumpset Size (Suction X Delivery in inch) : 1" X 1"

• High operating efficiency resulting in lower power consumption
• Good suction lift characteristics
• Inbuilt thermal overload protector in al single phase pumpsets
• Specially designed for wide voltage operation
• Dynamically balanced rotating parts including rotor and impeller ensures minimum vibration and longer life
• Back pull-out design for easy servicing and repair
• Double shielded ball bearings, so no need of external lubrication
• Mechanical seal is provided as per customers requirement.
