• High operating efficiency resulting in lower power consumption
• Good suction lift characteristics
• Specially designed for wide voltage operation
• Dynamically balanced rotating parts including rotor and impeller ensures minimum vibration and longer life
• Back pull-out design for easy servicing and repair
• Double shielded ball bearings, so no need of external lubrication

• Power Range : 1.5 Kw - 5.5 Kw (2.0 HP - 7.5 HP)
• Version : Three Phase, 380-415V, 50Hz AC Supply
• Speed : 1440 RPM
• Maximum Total Head : 12 Mtr.
• Maximum Flow Rate : 3160 LPM
• Maximum Suction Lift : 7 Mtr.
• Degree of Protection : IP 44
• Class of Insulation : B
• Maximum Ambient Tem. : 40 C
• Sealing : Stuffing Box
• Type of Duty : S1 (Continuous)
• Direction of Rotation : Three Phase - Electrically Reversible
• Nominal Pumpset Size (Suction X Delivery) : 80 X 80, 100 X 100, 125 X 125, 150 X 150 (All size in mm)

• High operating efficiency resulting in lower power consumption
• Good suction lift characteristics
• Specially designed for wide voltage operation
• Dynamically balanced rotating parts including rotor and impeller ensures minimum vibration and longer life
• Back pull-out design for easy servicing and repair
• Double shielded ball bearings, so no need of external lubrication
