• Outlet : SS-304
• Suction : SS-304
• Outer Shell : SS-304
• Rotor Screw : Stainless Steel
• Stator : Rubber Coated Alloy

• Check valve housing : SS-304
• Check valve : PC
• Suction : SS-304
• Outer Shell : SS-304
• Impeller : POM
• Bowl : PC
• Pump Bush : NBR
• Pump Sleeve : Stainless Steel
• Pump Shaft : Stainless Steel
• Coupling / Pump Couple : Stainless Steel

• Eco-Friendly
• Zero running cost
• Easy start at low irradiation & works in wide voltage   operation range
• Less maintenance cost. (Fit & Forgrt)
• Simple installatoin

• Power Range : 1.0 HP to 2.0 HP
• Operating Speed : 0 – 3100 RPM
• DC Power Range : 900 Wp – 2000 Wp
• DC Voltage Range : 70 Vmp – 110 Vmp
• Head Range : 30 Mtr – 90 Mtr
• Discharge Range : 8000 LPD – 30000 LPD
• Type of Duty : S1

• Equipped with Highly Efficient Solar Controller to get More    Discharge and Early Wake Up.
• Controller also includes inbuilt Short-Circuit, Phase Loss,    Over Voltage, Under Voltage, Motor Overload and Dry -    Running protection.
• Pumps are designed by Casing Stresses.
• NEMA Dimension Standards.
• Excellent output in Low Radiation.
