• High operating efficiency resulting in lower power consumption
• Good suction lift characteristics
• Specially designed for wide voltage operation
• Dynamically balanced rotating parts including rotor and impeller ensures minimum vibration and longer life
• Back pull-out design for easy servicing and repair
• Double shielded ball bearings, so no need of external lubrication
• All Model fitted to Mechanical seal

• Power Range : 0.37 Kw - 0.75 Kw (0.5 HP - 1.0 HP)
• Version : Single Phase, 220-240V, 50Hz AC Supply
• Speed : 1440 RPM
• Maximum Total Head : 18 Mtr.
• Maximum Flow Rate : 4200 LPH
• Maximum Suction Lift : 8 Mtr.
• Degree of Protection : IP 44
• Class of Insulation : B
• Maximum Ambient Tem. : 40 C
• Sealing : Mechanical Seal
• Type of Duty : S1 (Continuous)
• Direction of Rotation : Single Phase - Clockwise from driving end
• Nominal Pumpset Size (Suction X Delivery) : 25mm X 25mm
